Maxx 90 Rim Clamp Tire Changer
Features of Coats MAXX 90 Rim Clamp Tire Changer
![](https://coatscompany.com/wp-content/uploads/2023/05/maxx-90-poster.png)
![The leverless bead lifter hooks under a tire and lifts it up and away from the wheel](https://coatscompany.com/wp-content/uploads/2023/05/Leverless-Bead-Lifter-In-Action.jpg)
Our Leverless Bead Lifter
Mounts and demounts tires without traditional tire tools that can potentially mar the wheel surface. Makes the process faster and easier while reducing potential for damage.
![2 bead sealing nozzles point at an upward angle toward a tire clamped on the tire changer](https://coatscompany.com/wp-content/uploads/2023/03/DSC_0178-Edit-small-1.jpg)
Dual Nozzle
An increased air flow seals tough beads twice as fast to get your jobs done more efficiently.
![A single, steel, extended clamp with black grips](https://coatscompany.com/wp-content/uploads/2023/05/Extended-Clamps.png)
30” Extended Clamps
Clamp passenger car, light truck or extreme custom applications without changing anything for maximum time savings and damage avoidance.
![](https://coatscompany.com/wp-content/uploads/2023/05/speed-power.jpg)
Speed, Power, and Flexibility
When time is critical, the 220V 2-Speed option on the Maxx 90 gets the job done fast.
Taking the Hassle Out of the Hustle
Car and Light Truck
6" - 24" External Rim Diameter
50” Max Tire Diameter
16" Max Rim Width
Hand & Foot Control Bead Loosening System
High Pressure Dual Nozzle
Swing Away Arm & Leverless Bead Lifter Mount/Dismount System
Robo-Arm® Bead Depressor
RoboRoller
30” Max 4 Rim Clamp, Air Cylinder Operated
220 V, 2 HP, 2 Speed Electric Motor
110 - 175 psi, 15 scfm Air Motor
74"w x 44"d x 88"h Footprint
![Front diagram of a Maxx 90 showing height, width, and length, dimensions](https://coatscompany.com/wp-content/uploads/2023/05/Maxx-90-Footprint.png)
-
Electric 220V Model: 800MAXX90220
-
Air Model: 800MAXX90A
-
Ship Weight: 874 lbs
GALLERY
DOCUMENTS
SPECIFICATIONS
Car and Light Truck
6" - 24" External Rim Diameter
50” Max Tire Diameter
16" Max Rim Width
Hand & Foot Control Bead Loosening System
High Pressure Dual Nozzle
Swing Away Arm & Leverless Bead Lifter Mount/Dismount System
Robo-Arm® Bead Depressor
RoboRoller
30” Max 4 Rim Clamp, Air Cylinder Operated
220 V, 2 HP, 2 Speed Electric Motor
110 - 175 psi, 15 scfm Air Motor
74"w x 44"d x 88"h Footprint
![Front diagram of a Maxx 90 showing height, width, and length, dimensions](https://coatscompany.com/wp-content/uploads/2023/05/Maxx-90-Footprint.png)
-
Electric 220V Model: 800MAXX90220
-
Air Model: 800MAXX90A
-
Ship Weight: 874 lbs
